商洛水平網帶輸送機制造廠家

網帶輸送機網帶輸送機:模塊式網帶用延伸在輸送帶整個寬度上的塑料鉸接銷，把注塑成型的網帶組裝成互鎖單元。這種方法增加了輸送帶的強度，并可以組接成任何需要的寬度和長度。擋板和側板也可以用鉸接銷互鎖，成為輸送帶整體部件之一。網帶輸送機結構形式有:水平直線輸送、爬坡輸送等形式，輸送帶可增設擋板、側擋板。插件線輸送機插件線輸送機采用專用鋁合金導軌，靠近操作面一邊的導軌固定，另一邊可調節移動，保證操作每一次拾取元件距離小，提高生產效率。該設備對于電子基板的流水作業非常適合，其導軌間可調，各式基板懸空流動，帶動基板引走的鏈條有不銹鋼鏈條、碳鋼鏈條、塑鋼鏈條、導軌及機架有鋁型材、不銹鋼、碳鋼等多種材質，可供選擇。主要技術參數.鏈條節距:25.4mm~203.2mm板鏈輸送機寬度:200mm~800mm(寬度超過800mm時，可使用雙板鏈結構)故障分析.在實際使用中，由于接鏈環往往比輸送鏈條稍大，磨損情況比較嚴重，因此接鏈環成了整個傳送鏈條中的薄弱點。它的損壞形式主要為嚴重磨損、斷裂、拉開，其產生的原因主要為:1、長期承受脈動載荷，疲勞破壞;2、連接銷或螺栓松動脫落，未能及時發現補充，致使接鏈環受力不均或拉托;3、對于立環，單邊磨損更為嚴重，如不及時更換，容易發生斷裂;4、卡鏈后，會產生很大的動載荷和沖擊載荷，導致傳送鏈條運動速度的瞬時巨大波動，使傳送鏈條運行不平穩，從而加速接鏈環磨損或斷裂;5、生產制造質量較差，耐磨性差或韌性差硬度低，或者出現應力集中產生疲勞裂紋，導致強度不足。鏈板輸送機的連接環損壞大致就是由于以上五個原因造成的，這要求企業在使用鏈板輸送機時需要定期做好設備的檢修工作，發現問題立即進行處理。網帶輸送機是在一定的線路上連續輸送物料的物料搬運機械，又稱連續輸送機，可分為網帶式和網鏈式。輸送機可進行水平、傾斜和垂直輸送，也可組成空間輸送線路，輸送線路一般是固定的。輸送機輸送能力大，運距長，還可在輸送過程中同時完成若干工藝操作.網帶輸送機制作采用的材質有，碳鋼，201不銹鋼，304不銹鋼。材質.輸送帶的材質有:碳鋼、不銹鋼、熱塑鏈，根據您的產品的需要可選取不同寬度、不同形狀的鏈板來完成平面輸送、平面轉彎、、下降等要求。分類.塑鋼網帶輸送機:是對傳統皮帶式輸送機的補充，它克服了皮帶機皮帶撕裂、刺破、腐蝕的缺點，為客戶提供的一種、快捷、維護簡單的輸送方式。由于網帶輸送機使用模塊網帶，而且傳動方式采用鏈輪驅動，所以輸送網帶不易蛇行、跑偏，并且由于帶子厚實可以經得起切割、碰撞，及耐油、耐水等特性，使得各業界使用時不致在維修保養上產生困擾，尤其在更換輸送帶上塑鋼網帶輸送機更減少一筆開銷。采用不同材質的網帶可以起到不同的輸送作用并且滿足不同環境的需要，我們通過塑料材質的改性使輸送帶能夠滿足環境溫度零下-10度至120攝氏度之間的輸送要求，網帶節距有12.7、19.05、25.4、27.2、38.1、50.8可選，開孔率由2%至48%可選。用途.廣泛應用于飲料瓶、鋁罐、藥品、、食品等行業的輸送，通過選用不同的網帶可以制作成儲瓶臺、機、殺菌機、蔬菜清洗機、冷瓶機以及肉食品輸送等行業專用設備考慮網帶承受拉力限制，長單線長度一般不超過20米。模塊式輸送機.模塊式網帶用延伸在輸送帶整個寬度上的塑料鉸接銷，把注塑成型的網帶組裝成互鎖單元。這種方法增加了輸送帶的強度，并可以組接成任何需要的寬度和長度。擋板和側板也可以用鉸接銷互鎖，成為輸送帶整體部件之。輸送帶的材質有: PP(聚丙烯)、PE(聚乙烯)、ACETAL(乙縮醛)、NYLON(尼龍)。結構形式水平直線輸送、爬坡輸送等形式，輸送帶可增設擋板、側擋板。金屬網帶輸送機.采用金屬網帶作為輸送載體。驅動方式減速電機驅動。調速方式變頻調速、無極變速。機架材質不銹鋼、碳鋼。使用范圍適用于各行業的烘干、去濕、清洗、速凍等工藝。1、工作原理輸送鏈為套筒滾子鏈，連續斗式結構，用于高溫熟料的水平、爬坡。2、主要特點◆ 輸送能力大: 輸送能力可達526m3/h，傾角可達60度。耐高溫、可輸送溫度小于600度的物料。◆ 輸送鏈是由牽引鏈、承載鏈和正向搭接(或反向搭接)的料斗組成，三部分可自由裝卸。◆ 承重的滾輪中帶有滾動軸承，以滾動摩擦代替以往的滑動摩擦，運行阻力降低55%-65%，大大減少了輸送機的功率消耗，能耗低。◆ 牽引鏈和承載鏈分開，使結構簡化，成本降低，安裝維修方便。◆ 使用壽命長: 牽引鏈使用長節距、套筒滾子鏈，鏈條個零件均采用合金鋼材料;并經熱處理加工，耐磨。輸送部分及物料的重量由承重件承擔;鏈條不再承擔重量，減少磨損。◆ 工藝布置多樣: 可水平、傾斜，還可以由多段水平、傾斜組合布置。3、適用領域◆ 廣泛用于水泥、造紙、制糖、化工等行業。適合用于物料渣漿式、顆粒狀等。產品列表.1.移動式輸送機 適應運送散裝或包裝的糧食及小顆粒物料的輸送，裝卸，碼垛，倒倉多種作用，并可由多臺串聯或用其它機械聯合配套使用。可以在露天庫內作業。由機架，傳動，自動升降裝置，托棍，輸送帶。2.爬坡皮帶輸送機運用輸送帶的連續或間歇運動輸送500kg以下的物品或粉狀、顆裝物品。爬坡式皮帶輸送機運用于有高低差的輸送情況下，可完成連續輸送，能平滑的與滾筒輸送機或鏈板輸送機接駁。3.轉彎皮帶輸送機采用專業的膠帶計算程序軟件計算出膠帶在各個轉彎點所受到的拉力，根據這些參數算出各個轉彎點及轉彎點前后的托輥支架的傾斜角度和托輥傾斜角度，確保膠帶在轉彎點運行的可靠性。4.柔性輸送機柔性輸送鏈板是在傳統鏈板的基本上作了很大改進使鏈板的運行性能有了質的提高。 輸送產品有:皮帶輸送機，鏈板輸送機，滾筒輸送機，網帶輸送機，鏈條輸送機，柔性輸送機。5.皮帶輸送機運用輸送帶的連續或間歇運動來輸送各種輕重不同的物品，既可輸送各種散料，也可輸送各種紙箱、包裝袋等單件重量不大的件貨，用途廣泛。6.鏈板輸送機通過制作多排一體，使輸送機變的很寬，并形成差速，使多列在無擠壓的情況下變?yōu)閱瘟校瑯右部梢允箚瘟凶兂啥嗔胁⑿凶呔徛瑥亩a生儲存量。7.輸送機是在一定的線路上連續輸送物料的物料搬運機械，又稱連續輸送機。輸送機可進行水平、傾斜和垂直輸送，也可組成空間輸送線路，輸送線路一般是固定的。輸送機輸送能力大，運距長。8.網帶輸送機是對傳統皮帶式輸送機的一次革命，它克服皮帶輸送機維護困難，帶子易被撕裂、刺破、腐蝕的缺點，為客戶提供的一種、快捷、維護簡單的輸送方式。由于此類輸送機使用模塊式塑料輸送帶。9.不銹鋼輸送機全不銹鋼結構外形，鏈板式輸送帶，無外露緊固件，全新設計，美觀大方;輸送性能平穩可靠，無極調度，使用方便;用于外觀要求好，質量要求高等精密設備的配套使用。10.不銹鋼網帶輸送機采用不銹鋼網帶作為載體進行輸送，適用于各種食品行業的烘干、蒸煮、油炸、去濕、冷凍等及金屬行業的冷卻、噴淋、清洗、瀝油、熱處理等工藝。11.網帶鏈輸送機:紙箱裝啤酒網帶鏈輸送機、脫水蔬菜網帶鏈輸送機、罐類網帶鏈輸送機、蓄電池網帶鏈輸送機、輪胎網帶鏈輸送機、蔬菜網帶鏈輸送機、水產網帶鏈輸送機、水果網帶鏈輸送機、膨化食品網帶鏈輸送機、肉食品小包裝網帶鏈輸送機、果蔬類網帶鏈輸送機、肉類分割網帶鏈輸送機。12.鋁合金網帶輸送機采用鋁合金網帶作為載體進行輸送，適用于各種食品，醫藥，化學品行業。常用帶寬.網帶輸送機的常用帶寬有:100毫米，150毫米，200毫米，250毫米，300毫米，400毫米，500毫米，650毫米，800毫米，1000毫米，1200毫米，1400毫米，1600毫米，1800毫米，2000毫米，2200毫米，2400毫米另外不銹鋼網帶輸送機的輸送機網帶是一種非標的產品，所以帶寬是可以定做的.常用帶速.網帶輸送機的常用帶速:0.25米/秒，0.4米/秒，0.5米/秒，0.8米/秒，1.0米/秒，1.25米/秒，1.6米/秒，2.0米/秒，2.5米/秒，3.15米/秒，4.0米/秒，4.5米/秒，5.0米/秒，5.6米/秒，6.5米/秒。日常保養.1、網帶輸送機在工作過程中應有固定人員看管。看管人員必須是具有一般技術常識及對本輸送機的性能比較熟悉。2、企業應制定輸送機應"設備維護、檢修、操作規程"以便看管人員遵守。看管人員必須有交接班制度。 3、向皮帶輸送機給料應該均勻，不得給料過多而使進料漏斗被物料塞滿而溢出。4、輸送機工作過程中，非看管人員不得靠近機器;任何人員不得觸摸任何旋轉部件。發生故障時，必須立即停止運轉，故障。如有不易立即但對工作無過大影響的缺陷，應作記載，待檢修時。5、看管輸送機時，應經常觀察各部件的運行情況，檢查各處連接螺栓，發現松動及時擰緊。但禁止輸送機運轉時，對輸送機的運轉部件進行清掃和修理。6、尾部裝配的螺旋拉緊裝置應調整適宜，保持輸送帶具有正常工作的拉力。看管人員應經常觀察輸送帶的工作情況，局部損壞的地方，應視其破損程度(既是否對生產造成影響)而決定是否立即更換或待檢修時更換新的。對拆下的輸送帶應視其磨損程度而另作它用。7、看管皮帶輸送機時在于觀察其工作狀態、清掃、潤滑以及檢查調整螺旋拉緊裝置等零星工作。8、網帶輸送機一般情況下應在無負荷時起動，在物料卸完后停車。9、輸送機除在使用過程中保持正常的潤滑和拆換個別損壞的零部件外，每工作6個月必須檢修一次。檢修時必須在使用中及記載的缺陷，拆換損廢零部件及更換潤滑油等。10、企業可根據輸送機的工作條件制定檢修周期。使用方法.在網帶輸送機運行前，首先要確認網帶輸送機設備、人員、被輸送物品均處于完好的狀態;其次檢查各運動部位正常，檢查所有電氣線路是否正常，正常時才能將皮帶輸送機投入運行。要檢查供電電壓與設備額定電壓的差別不超過±5%。網帶輸送機的具體操作如下:1.合上總電源開關，檢查設備電源是否正常送入且電源指示燈是否亮。正常后進行下一步操作。2.合上各回路的電源開關，檢查是否正常。正常狀態下為:設備不動作，網帶輸送機運行指示燈不亮，變頻器等設備的電源指示燈亮，變頻器的顯示面板顯示正常。3.按照工藝流程依次啟動各電氣設備，上一個電氣設備啟動正常后再進行下一個電氣設備的啟動。4.在網帶輸送機運行中，必須遵守被輸送物品設計中物品的規定，遵守網帶輸送機的運送能力。其次，要注意各類人員不得觸及網帶輸送機的運動部分，非專業人員不得隨意接觸電氣元件、控制按鈕等。，網帶輸送機運行中不能對變頻器后級斷路，如確定維修需要，則必須在停止變頻運行的情況下才能進行，否則可能損壞變頻器。5.網帶輸送機運行停止，按下停止按鈕待系統全部停止后方能切斷總電源。網帶輸送機的構造原理：采用模塊式網帶，將輸送帶整個寬度上的金屬鉸接銷進行延伸，并且將制造成型的網帶進行組裝構成互鎖單元。網帶輸送機的優點：因結構的特殊性，從而增加了輸送帶的強度以及可利用性，不論是在寬度上還是在長度上都進行無條件組接。同時網帶輸送機的擋板與側板也都可以進行鉸接銷互鎖，成為輸送帶整體部件之一。網帶輸送機的材質：可分為碳鋼、不銹鋼、熱塑鏈。如若所需產品可以選取不同寬度、不同形狀的鏈板來完成平面輸送、平面轉彎、、下降等要求。網帶輸送機結構形式有：水平直線輸送、爬坡輸送等形式，輸送帶可增設擋板、側擋板。網帶輸送機用途：廣泛應用于飲料瓶、鋁罐、藥品、、食品等行業的輸送，通過選用不同的網帶可以制作成儲瓶臺、機、殺菌機、蔬菜清洗機、冷瓶機以及肉食品輸送等行業專用設備。【網帶輸送機說明】 網帶輸送機/網帶輸送線/網帶流水線廣泛應用于飲料瓶、鋁罐、藥品、、食品等行業的輸送，通過選用不同的網帶可以制作成儲瓶臺、機、殺菌機、蔬菜清洗機、冷瓶機以及肉食品輸送等行業專用設備。適用于各行業的烘干、去濕、清洗、速凍等工藝。·網帶材質： 碳鋼、不銹鋼、PP（聚丙烯）、PE（聚乙烯）、ACETAL（乙縮醛）、NYLON（尼龍）等材料。（某些帶型符合FDA、USDA標準，因此廣泛用于食品加工業。）·結構形式：水平直線輸送、爬坡輸送、轉彎輸送等多種形式，輸送帶上還可增設擋板、側板等附件，滿足各種工藝需求。·網帶輸送機小轉彎半徑：R=W*2.3。·設備特點：1，網帶輸送克服了污染問題，使用符合衛生標準的塑膠材料一體成型，構造上沒有毛細孔及縫隙。輸送豬肉、雞鴨、魚蝦等都不會被產品所帶的血水、油脂等污染源滲透，更不會吸附任何雜質于輸送帶表面。可以達到一個的制造過程；2，塑鋼網帶輸送機是對傳統皮帶式輸送機的補充，它克服了皮帶機皮帶撕裂、刺破、腐蝕的缺點，為客戶提供的一種、快捷、維護簡單的輸送方式。由于網帶輸送機使用模塊網帶，而且傳動方式采用鏈輪驅動，所以輸送網帶不易蛇行、跑偏，并且由于帶子厚實可以經得起切割、碰撞，及耐油、耐水等特性，使得各業界使用時不致在維修保養上產生困擾，尤其在更換輸送帶上塑鋼網帶輸送機更減少一筆開銷。采用不同材質的網帶可以起到不同的輸送作用并且滿足不同環境的需要，我們通過塑料材質的改性使輸送帶能夠滿足環境溫度零下-10度至120攝氏度之間的輸送要求，網帶節距有12.7、19.05、25.4、27.2、38.1、50.8可選，開孔率由2%至48%可選。 螺旋輸送機：【螺旋輸送機說明】 【標準規格圖表】 螺旋輸送機，又稱螺旋機，螺旋輸送線，是冶金、建材、化工、糧食及機械加工等部門廣泛應用的一種連續輸送設備，與其它輸送設備相比，具有整機截面尺寸小、密封性能好、運行平穩可靠、操作、維修簡便等優點。·螺旋輸送機機身結構材質：碳鋼烤漆和不銹鋼。·螺旋輸送機輸送圈數總長度：碳鋼底鏈60米、不銹鋼底鏈48米。 ·螺旋輸送機輸送寬度：200mm、300mm、400mm、600mm。·螺旋輸送機可升降高度：1.單一驅動6米，但依實際運載速度及載重須配合輸送圈數總長度而有所變動。2.可多臺串聯高度達20米。 ·適合行業：飲料、啤酒、卷煙、郵政、報業、印刷、食品、制藥、物流、電子等行業。·螺旋輸送機（一個電機）承重：碳鋼底鏈<750kg ·不銹鋼底鏈<600kg 螺旋輸送機 【規格表】螺旋輸送機/螺旋輸送線/螺旋流水線 型號 輸送寬度 直徑 升降高度 。 Net Conveyor Mesh belt conveyor: the modular mesh belt uses the plastic hinge pin extending over the entire width of the conveyor belt to assemble the injection molded mesh belt into an interlocking unit. This method increases the strength of the conveyor belt and can be assembled into any required width and length. The baffle and side plate can also be interlocked with hinged pins to become one of the integral parts of the conveyor belt. The structural forms of mesh belt conveyor include horizontal straight-line transportation lifting and climbing transportation etc. the conveyor belt can be added with lifting baffle and side baffle. Plug in line conveyor The plug-in line conveyor adopts special aluminum alloy guide rail. The guide rail on one side close to the operation surface is fixed and the other side can be adjusted and moved to ensure the minimum distance of pickup elements in each operation and improve production efficiency. The equipment is very suitable for the flow operation of electronic substrate. Its guide rails are adjustable and all kinds of substrates flow in the air. The chains driving the substrate are stainless steel chain carbon steel chain plastic steel chain guide rails and frames are made of aluminum profile stainless steel carbon steel and other materials. Main technical parameters Chain pitch: 25.4mm ~ 203.2mm Width of plate chain conveyor: 200mm ~ 800mm (double plate chain structure can be used when the width exceeds 800mm) Fault analysis In practical use because the chain link is often slightly larger than the conveying chain and the wear is more serious the chain link has become a weak point in the whole conveying chain. Its damage forms are mainly serious wear fracture and pulling and the main causes are: 1. Long term bearing pulsating load fatigue failure; 2. The connecting pin or bolt is loose and falls off which is not found and supplemented in time resulting in uneven stress or pulling support of the connecting link; 3. For the vertical ring the unilateral wear is more serious. If it is not replaced in time it is easy to break; 4. After the chain is jammed great dynamic load and impact load will be generated resulting in instantaneous and huge fluctuation of the moving speed of the transmission chain making the transmission chain run unstable so as to accelerate the wear or fracture of the chain link; 5. Poor manufacturing quality poor wear resistance or toughness low hardness or fatigue cracks due to stress concentration resulting in insufficient strength. The damage of the connecting ring of the chain plate conveyor is roughly caused by the above five reasons which requires enterprises to do a good job in equipment maintenance regularly when using the chain plate conveyor and deal with the problems immediately. Mesh belt conveyor is a material handling machine that continuously transports materials on a certain line also known as continuous conveyor which can be divided into mesh belt type and mesh chain type. The conveyor can carry out horizontal inclined and vertical conveying and can also form a spatial conveying line. The conveying line is generally fixed. The conveyor has large conveying capacity and long haul distance. It can also complete several process operations at the same time. The materials used for the production of mesh belt conveyor are carbon steel 201 stainless steel and 304 stainless steel. texture of material. The conveyor belt is made of carbon steel stainless steel and thermoplastic chain. According to the needs of your products chain plates with different widths and shapes can be selected to meet the requirements of plane conveying plane turning lifting and lowering. Classification Plastic steel mesh belt conveyor: it is a supplement to the traditional belt conveyor. It overcomes the shortcomings of belt tearing puncture and corrosion of belt conveyor and provides customers with a safe fast and simple maintenance transportation mode. Because the mesh belt conveyor uses modular mesh belt and the transmission mode is driven by sprocket the conveyor mesh belt is not easy to snake and deviate and because the belt is thick and can withstand cutting collision oil and water resistance it will not cause trouble in maintenance when used in various industries especially in replacing the plastic steel mesh belt conveyor on the conveyor belt which will reduce a sum of expenses. Mesh belts of different materials can play different conveying roles and meet the needs of different environments. Through the modification of plastic materials the conveyor belt can meet the conveying requirements of the ambient temperature between minus - 10 ℃ and 120 ℃. The mesh belt pitch can be selected from 12.7 19.05 25.4 27.2 38.1 and 50.8 and the opening rate can be selected from 2% to 48%. Purpose It is widely used in the transportation of beverage bottles aluminum cans drugs cosmetics food and other industries. By selecting different mesh belts it can be made into industry-specific equipment such as bottle storage platform elevator sterilizer vegetable cleaning machine bottle cooling machine and meat food transportation. Considering the tension limit of mesh belt the maximum single line length is generally no more than 20m. Modular conveyor The modular mesh belt uses a plastic hinge pin extending over the entire width of the conveyor belt to assemble the injection molded mesh belt into an interlocking unit. This method increases the strength of the conveyor belt and can be assembled into any required width and length. The baffle and side plate can also be interlocked with hinged pins to become an integral part of the conveyor belt. The materials of conveyor belt include PP (polypropylene) PE (polyethylene) acetal (acetal) and nylon (nylon). structural style In the form of horizontal straight-line conveying lifting and climbing conveying lifting baffle and side baffle can be added to the conveyor belt. Metal mesh belt conveyor The metal mesh belt is used as the conveying carrier. Driving mode Reduction motor drive. Speed regulation mode Variable frequency speed regulation stepless speed change. Frame material Stainless steel carbon steel. Scope of use It is suitable for drying dehumidification cleaning quick freezing and other processes in various industries. 1. Working principle The conveyor chain is a sleeve roller chain with continuous bucket structure which is used for horizontal and climbing of high-temperature clinker. 2. Main features ◆ large conveying capacity: the maximum conveying capacity can reach 526m3 / h and the maximum inclination can reach 60 degrees. High temperature resistant and can transport materials with temperature less than 600 ℃. ◆ the conveying chain is composed of traction chain bearing chain and hopper with forward lapping (or reverse lapping) and the three parts can be loaded and unloaded freely. ◆ the load-bearing roller is equipped with rolling bearing which replaces the previous sliding friction with rolling friction reducing the running resistance by 55% - 65% greatly reducing the power consumption of the conveyor and low energy consumption. ◆ the traction chain and bearing chain are separated to simplify the structure reduce the cost and facilitate installation and maintenance. ◆ long service life: the traction chain uses long pitch sleeve roller chain and all parts of the chain are made of alloy steel; After heat treatment it is wear-resistant. The weight of the conveying part and materials shall be borne by the bearing parts; The chain no longer bears weight and reduces wear. ◆ the process layout is diverse: it can be arranged horizontally and obliquely and can also be combined by multiple sections horizontally and obliquely. 3. Applicable fields ◆ widely used in cement papermaking sugar making chemical industry and other industries. It is most suitable for slurry and granular materials. Product list 1. The mobile conveyor is suitable for the transportation loading and unloading palletizing and warehouse transfer of bulk or packaged grain and small particle materials and can be used by multiple sets in series or combined with other machines. It can work in the open warehouse. It consists of frame transmission automatic lifting device supporting rod and conveyor belt. 2. The climbing belt conveyor uses the continuous or intermittent movement of the conveyor belt to transport articles below 500kg or powdery and granular articles. The climbing belt conveyor is applied to the transportation with height difference. It can complete continuous transportation and can be smoothly connected with roller conveyor or chain plate conveyor. 3. The turning belt conveyor adopts professional belt calculation program software to calculate the tensile force of the belt at each turning point and calculate the inclination angle of the idler support and idler before and after each turning point according to these parameters so as to ensure the reliability of belt operation at the turning point. 4. Flexible conveyor flexible conveyor chain plate has made great improvement on the basis of traditional chain plate so that the operation performance of chain plate has been qualitatively improved. Conveying products include: belt conveyor chain plate conveyor roller conveyor mesh belt conveyor chain conveyor and flexible conveyor. 5. The belt conveyor uses the continuous or intermittent movement of the conveyor belt to transport all kinds of articles with different weights. It can not only transport all kinds of bulk materials but also transport all kinds of cartons bags and other pieces of goods with small single weight which are widely used. 6. The chain plate conveyor makes the conveyor very wide and forms a differential speed by making multiple rows as a whole so that multiple rows can become a single row without extrusion. Similarly a single row can become multiple rows and walk slowly resulting in storage capacity. 7. Conveyor is a material handling machine that continuously transports materials on a certain line also known as continuous conveyor. The conveyor can carry out horizontal inclined and vertical conveying and can also form a spatial conveying line. The conveying line is generally fixed. The conveyor has large conveying capacity and long haul distance. 8. Mesh belt conveyor is a revolution of traditional belt conveyor. It overcomes the shortcomings of difficult maintenance of belt conveyor and easy tearing puncture and corrosion of belt. It provides customers with a safe fast and simple maintenance mode of transportation. Because these conveyors use modular plastic conveyor belts. 9. Stainless steel conveyor all stainless steel structure and shape chain plate conveyor belt no exposed fasteners new design beautiful and generous; Stable and reliable conveying performance stepless scheduling and convenient use; It is used for supporting precision equipment with good appearance and high quality requirements. 10. Stainless steel mesh belt conveyor adopts stainless steel mesh belt as the carrier for transportation. It is suitable for drying cooking frying dehumidification freezing etc. in various food industries and cooling spraying cleaning oil drainage heat treatment and other processes in metal industries. 11. Mesh belt chain conveyor: carton beer mesh belt chain conveyor dehydrated vegetable mesh belt chain conveyor tank mesh belt chain conveyor battery mesh belt chain conveyor tire mesh belt chain conveyor vegetable mesh belt chain conveyor aquatic mesh belt chain conveyor fruit mesh belt chain conveyor expanded food mesh belt chain conveyor meat food small packaging mesh belt chain conveyor Fruit and vegetable mesh belt chain conveyor meat segmentation mesh belt chain conveyor. 12. Aluminum alloy mesh belt conveyor adopts aluminum alloy mesh belt as carrier for transportation which is suitable for all kinds of food medicine and chemical industries. Common bandwidth The most commonly used belt widths of mesh belt conveyors are: 100 mm 150 mm 200 mm 250 mm 300 mm 400 mm 500 mm 650 mm 800 mm 1000 mm 1200 mm 1400 mm 1600 mm 1800 mm 2000 mm 2200 mm 2400 mm. In addition the conveyor mesh belt of stainless steel mesh belt conveyor is a non-standard product So the bandwidth can be customized Common belt speed The most commonly used belt speeds of mesh belt conveyors: 0.25m/s 0.4m/s 0.5m/s 0.8m/s 1.0m/s 1.25m/s 1.6m/s 2.0m/s 2.5m/s 3.15m/s 4.0m/s 4.5m/s 5.0m/s 5.6m/s 6.5m/s. Daily maintenance 1. The mesh belt conveyor shall be watched by fixed personnel during operation. The caretaker must have general technical knowledge and be familiar with the performance of the conveyor. 2. The enterprise shall formulate "equipment maintenance overhaul and safe operation procedures" for the conveyor to be observed by the caretaker. The caretaker must have a shift system. 3. The feeding to the belt conveyor shall be uniform and the feeding funnel shall not be filled with materials and overflow due to excessive feeding. 4. During the operation of the conveyor non caretaker personnel shall not approach the machine; No person shall touch any rotating parts. In case of failure the operation must be stopped immediately to eliminate the failure. If there are defects that are not easy to eliminate immediately but have no great impact on the work they shall be recorded and eliminated during maintenance. 5. When taking care of the conveyor always observe the operation of all parts check the connecting bolts everywhere and tighten them in time if they are loose. However it is absolutely forbidden to clean and repair the running parts of the conveyor when the conveyor is running. 6. The screw tensioning device assembled at the tail shall be adjusted appropriately to keep the conveyor belt with normal working tension. The caretaker shall often observe the working condition of the conveyor belt. For local damage it shall decide whether to replace it immediately or replace it when it is to be repaired according to its damage degree (i.e. whether it will affect the production). The removed conveyor belt shall be used for other purposes according to its wear degree. 7. When taking care of the belt conveyor it is necessary to observe its working state clean lubricate check and adjust the screw tensioning device and other sporadic work. 8. Generally the mesh belt conveyor shall be started when there is no load and stopped after the materials are unloaded. 9. In addition to maintaining normal lubrication and replacing individual damaged parts during use the conveyor must be overhauled every 6 months. During maintenance the defects in use and recorded must be eliminated and the damaged waste parts and components and lubricating oil must be replaced. 10. The enterprise can formulate the maintenance cycle according to the working conditions of the conveyor. usage method. Before the operation of the mesh belt conveyor first confirm that the equipment personnel and transported articles of the mesh belt conveyor are in a safe and intact state; Secondly check whether all moving parts are normal and whether all electrical circuits are normal. Only when they are normal can the belt conveyor be put into operation. Finally check that the difference between the power supply voltage and the rated voltage of the equipment does not exceed ± 5%. The specific operation of mesh belt conveyor is as follows: 1. Close the main power switch and check whether the equipment power is normally supplied and whether the power indicator is on. Proceed to the next step after normal operation. 2. Close the power switch of each circuit and check whether it is normal. Under normal conditions: the equipment does not act the operation indicator of mesh belt conveyor does not light the power indicator of frequency converter and other equipment is light and the display panel of frequency converter is normal. 3. Start all electrical equipment in sequence according to the process flow. Start the next electrical equipment after the previous electrical equipment starts normally. 4. During the operation of the mesh belt conveyor the provisions of the articles to be transported in the design and the transportation capacity of the mesh belt conveyor must be observed. Secondly it should be noted that all kinds of personnel shall not touch the moving part of the mesh belt conveyor and non professionals shall not touch electrical components control buttons etc. at will. Finally during the operation of the mesh belt conveyor the rear stage of the frequency converter cannot be opened. If the maintenance needs are determined it must be carried out when the frequency conversion operation is stopped otherwise the frequency converter may be damaged. 5. When the mesh belt conveyor stops running press the stop button and cut off the main power supply after all the systems stop. Structural principle of mesh belt conveyor: modular mesh belt is adopted to extend the metal hinge pin on the whole width of the conveyor belt and the manufactured mesh belt is assembled to form an interlocking unit. Advantages of mesh belt conveyor: due to the particularity of structure the strength and availability of conveyor belt are increased. Unconditional assembly is carried out both in width and length. At the same time the baffle and side plate of the mesh belt conveyor can also be interlocked with hinge pins which becomes one of the integral parts of the conveyor belt. Material of mesh belt conveyor: it can be divided into carbon steel stainless steel and thermoplastic chain. If required chain plates with different widths and shapes can be selected to meet the requirements of plane conveying plane turning lifting and lowering. The structural forms of mesh belt conveyor include horizontal straight-line transportation lifting and climbing transportation etc. the conveyor belt can be added with lifting baffle and side baffle. Purpose of mesh belt conveyor: it is widely used in the transportation of beverage bottles aluminum cans drugs cosmetics food and other industries. By selecting different mesh belts it can be made into industry-specific equipment such as bottle storage platform elevator sterilizer vegetable cleaning machine bottle cooling machine and meat food transportation. [description of mesh belt conveyor] Mesh belt conveyor / mesh belt conveyor line / mesh belt assembly line are widely used in beverage bottles aluminum cans drugs cosmetics and food
